IRONMAKING REFRACTORIES

product details

CASTABLE FOR MIXER FURNACE AND IRON LADLE

Features and Scope of Application:Alumina silicon carbide based castable has good thermal shock resistance,good corrosion resistance and scouring resistance.It is the best refractories for mixer furnace and iron ladle.It can be applied to monolithic casting for small and medium-sized ladle.It has features of longer service life,convenient construction and easy maintenance.

Item		Index
ω(Al,O₄)/% ≥		70
ω(SiC)/% ≥		10
(110℃×24h)/(g/cm²)B.D ≥		2.90
MPa C.C.S ≥	110℃×24h	25
	1400℃×3h	45
(1450℃×3h)/%PLC		±0.5

REBONDED FUSED MAGNESIA CHROME BRICK

The rebonded fused magnesia chrome brick is made from fused magnesia chrome clinker,and mainly used in critical area of refining furnace,such as AOD、VOD、RH、DH、SKF,etc.

Item	Index
Item	DMGe-12	DMGe-14	DMGe-16	DMGe-18	DMGe-20	DMGe-22	DMGe-26	DMGe-30
ω(MgO)/% ≥	70	68	65	60	60	55	50	45
ω(Cr₂O₃)/% ≥	12	14	16	18	20	22	26	30
ω(SiO₂)/ %≤	2.0	1.8	1.8	1.5	1.5	1.5	1.5	1.5
%A.P ≤	16	16	16	15	15	15	15	15
MPa C.C.S ≥	45	45	50	50	55	55	60	60
0.2MPa	1700	1700	1700	1700	1700	1700	1700	1700

MAGNESIA BRICK

High purity magnesia brick is made from high quality magnesia clinker as raw material by high pressure shaping and high temperature firing. Its specifications and hight temperture property could reach the level of products produced at similar home and abroad.

Characteristics: good strength at high temperature, good corrosion resistance, good wearing resistance and good cract resistance.

Application: high temperature parts of converter and EAF and all kinds of industrial furnaces and kilns.

Item	Index
Item	MZ-91	MZ-95	MZ-96	MZ-97	MZ-98
ω(MgO)/% ≥	91	94.5	95.5	96.5	97.5
ω(CaO)/% ≤	3.5	2	2	2	1.5
%A.P ≤	17	17	17	16	16
MPa C.C.S ≥	60	60	60	70	70
0.2MPa℃ RUL ≥	1550	1600	1650	1700	1700

MAGNESIA HERSYNITE BRICK

It is made from high purity magnesia clinker and hersynite as main raw material, it has good toughness and thermal shock resistance, depending on the strict control of firing temperature and firing atmosphere. It has better performance than good quality MgO chrome brick because of its good adhering to kiln coating and good corrosion resistance. It is the replacement product for burning zone of large scale dry process rotary cement kiln lining. The service life reaches more than one year.

Item		Index
		TZMGe-85
ω(MgO)/% ≥		85
ω(Al₂O₃)/% ≥		5.0
ω(SiO₂)/% ≤		1.0
ω(Fe₂O₃)/% ≥		4.0
%A.P ≤		17
/(g/cm³)B.D ≥		2.96
MPa C.C.S ≥		50
0.2MPaTod/℃ RUL ≥		1700
950℃,T.R Air ≥		100
(1000℃)W/(m·k)T.C ≤		2.6
(1400℃)/%T.E		1.6

MAGNESIA DOLOMITE BRICK

Magnesia dolomite brick is made from two steps calcined magnesia calcium clinker and high purity (fused or sintered) magnesia clinker as raw material after high pressure shaped at high temperature firing and vacuum pressure impregnation.it is environmental protection product with good high temperature creep and slag resistance.It’s the ideal environmental protection material for AOD、VOD refining furnace.

Item	Index
Item	MC-15A	MC-15B	MC-20A	MC-20B	MC-25A	MC-25B	MC-30Al	MC-30B
ω(MgO)/% ≥	75	70	70	65	65	60	60	55
ω(CaO)/% ≥	15	15	20	20	25	25	30	30
ω(E)/(A+F+S)≤	2.8	3.2	2.8	3.5	3.0	3.5	3.0	3.5
%A.P ≤	10	10	10	10	10	10	10	10
MPa C.C.S ≥	55	50	55	50	55	50	55	50
(g/cm³)B.D ≥	2.95	2.95	2.95	2.95	2.95	2.95	2.98	2.98
0.2MPaT₀g/℃ RUL ≥	1700	1680	1700	1680	1700	1680	1700	1680
